Design tilting LED floor
For 'Vrienden van Amstel Live! 2013' a tilting construction for a 6 by 6 meter LED video floor in the surface of the stage was asked. By tilting the floor a bridge could be created to a higher part of the stage. The LED floor could also be used as a vertical screen.
Neo supported the creative ideas with a technical concept. This concept was further developed to a solution based on standard (truss) components. The tilting movement was driven by two hydraulic cylinders, servo valve speed control and position feedback with pull wire encoders.
In addition to the construction for tilting, a special floor structure was designed for the (vertical) fixation of the LED video tiles.
